Gtk::CellRendererToggle Class Reference
[TreeView Classes]

Renders a toggle button in a cell. More...

Inherits Gtk::CellRenderer.

Collaboration diagram for Gtk::CellRendererToggle:

[legend]

List of all members.

Public Member Functions
virtual	~CellRendererToggle ()
GtkCellRendererToggle*	gobj ()
	Provides access to the underlying C GtkObject.
const GtkCellRendererToggle*	gobj () const
	Provides access to the underlying C GtkObject.
	CellRendererToggle ()
bool	get_radio () const
	Returns whether we're rendering radio toggles rather than checkboxes.
void	set_radio (bool radio=true)
	If radio is true, the cell renderer renders a radio toggle (i.e. a toggle in a group of mutually-exclusive toggles).
bool	get_active () const
	Returns whether the cell renderer is active.
void	set_active (bool setting=true)
	Activates or deactivates a cell renderer.
bool	get_activatable () const
	Returns whether the cell renderer is activatable.
void	set_activatable (bool setting=true)
	Makes the cell renderer activatable.
Glib::SignalProxy1< void, const Glib::ustring& >	signal_toggled ()
	The toggled signal is emitted when the cell is toggled.
Glib::PropertyProxy< bool >	property_activatable ()
	The toggle button can be activated.
Glib::PropertyProxy_ReadOnly < bool >	property_activatable () const
	The toggle button can be activated.
Glib::PropertyProxy< bool >	property_active ()
	The toggle state of the button.
Glib::PropertyProxy_ReadOnly < bool >	property_active () const
	The toggle state of the button.
Glib::PropertyProxy< bool >	property_radio ()
	Draw the toggle button as a radio button.
Glib::PropertyProxy_ReadOnly < bool >	property_radio () const
	Draw the toggle button as a radio button.
Glib::PropertyProxy< int >	property_indicator_size ()
	Size of check or radio indicator.
Glib::PropertyProxy_ReadOnly< int >	property_indicator_size () const
	Size of check or radio indicator.
Protected Member Functions
virtual void	on_toggled (const Glib::ustring& path)
Related Functions
(Note that these are not member functions.)
Gtk::CellRendererToggle*	wrap (GtkCellRendererToggle* object, bool take_copy=false)
	A Glib::wrap() method for this object.

---

Detailed Description

Renders a toggle button in a cell.

The button is drawn as a radio- or checkbutton, depending on the radio property. When activated, it emits the toggled signal.

---

Constructor & Destructor Documentation

virtual Gtk::CellRendererToggle::~CellRendererToggle

(

)

[virtual]

Gtk::CellRendererToggle::CellRendererToggle

(

)

---

Member Function Documentation

bool Gtk::CellRendererToggle::get_activatable

(

)

const

Returns whether the cell renderer is activatable.

See set_activatable().

Since gtkmm 2.18:

Returns:

true if the cell renderer is activatable.

bool Gtk::CellRendererToggle::get_active

(

)

const

Returns whether the cell renderer is active.

See set_active().

Returns:

true if the cell renderer is active.

bool Gtk::CellRendererToggle::get_radio

(

)

const

Returns whether we're rendering radio toggles rather than checkboxes.

Returns:

true if we're rendering radio toggles rather than checkboxes.

const GtkCellRendererToggle* Gtk::CellRendererToggle::gobj

(

)

const [inline]

Provides access to the underlying C GtkObject.

Reimplemented from Gtk::CellRenderer.

GtkCellRendererToggle* Gtk::CellRendererToggle::gobj

(

)

[inline]

Provides access to the underlying C GtkObject.

Reimplemented from Gtk::CellRenderer.

virtual void Gtk::CellRendererToggle::on_toggled

(

const Glib::ustring &

path

)

[protected, virtual]

Glib::PropertyProxy_ReadOnly<bool> Gtk::CellRendererToggle::property_activatable

(

)

const

The toggle button can be activated.

You rarely need to use properties because there are get_ and set_ methods for almost all of them.

Returns:

A PropertyProxy that allows you to get or set the property of the value, or receive notification when the value of the property changes.

Glib::PropertyProxy<bool> Gtk::CellRendererToggle::property_activatable

(

)

The toggle button can be activated.

You rarely need to use properties because there are get_ and set_ methods for almost all of them.

Returns:

A PropertyProxy that allows you to get or set the property of the value, or receive notification when the value of the property changes.

Glib::PropertyProxy_ReadOnly<bool> Gtk::CellRendererToggle::property_active

(

)

const

The toggle state of the button.

You rarely need to use properties because there are get_ and set_ methods for almost all of them.

Returns:

A PropertyProxy that allows you to get or set the property of the value, or receive notification when the value of the property changes.

Glib::PropertyProxy<bool> Gtk::CellRendererToggle::property_active

(

)

The toggle state of the button.

You rarely need to use properties because there are get_ and set_ methods for almost all of them.

Returns:

A PropertyProxy that allows you to get or set the property of the value, or receive notification when the value of the property changes.

Glib::PropertyProxy_ReadOnly<int> Gtk::CellRendererToggle::property_indicator_size

(

)

const

Size of check or radio indicator.

You rarely need to use properties because there are get_ and set_ methods for almost all of them.

Returns:

A PropertyProxy that allows you to get or set the property of the value, or receive notification when the value of the property changes.

Glib::PropertyProxy<int> Gtk::CellRendererToggle::property_indicator_size

(

)

Size of check or radio indicator.

You rarely need to use properties because there are get_ and set_ methods for almost all of them.

Returns:

A PropertyProxy that allows you to get or set the property of the value, or receive notification when the value of the property changes.

Glib::PropertyProxy_ReadOnly<bool> Gtk::CellRendererToggle::property_radio

(

)

const

Draw the toggle button as a radio button.

You rarely need to use properties because there are get_ and set_ methods for almost all of them.

Returns:

A PropertyProxy that allows you to get or set the property of the value, or receive notification when the value of the property changes.

Glib::PropertyProxy<bool> Gtk::CellRendererToggle::property_radio

(

)

Draw the toggle button as a radio button.

You rarely need to use properties because there are get_ and set_ methods for almost all of them.

Returns:

A PropertyProxy that allows you to get or set the property of the value, or receive notification when the value of the property changes.

void Gtk::CellRendererToggle::set_activatable

(

bool

setting = true

)

Makes the cell renderer activatable.

Since gtkmm 2.18:

Parameters:

setting

The value to set.

void Gtk::CellRendererToggle::set_active

(

bool

setting = true

)

Activates or deactivates a cell renderer.

Parameters:

setting

The value to set.

void Gtk::CellRendererToggle::set_radio

(

bool

radio = true

)

If radio is true, the cell renderer renders a radio toggle (i.e. a toggle in a group of mutually-exclusive toggles).

If false, it renders a check toggle (a standalone boolean option). This can be set globally for the cell renderer, or changed just before rendering each cell in the model (for Gtk::TreeView, you set up a per-row setting using Gtk::TreeViewColumn to associate model columns with cell renderer properties).

Parameters:

radio

true to make the toggle look like a radio button.

Glib::SignalProxy1< void,const Glib::ustring& > Gtk::CellRendererToggle::signal_toggled

(

)

The toggled signal is emitted when the cell is toggled.

Parameters:

path

string representation of TreePath describing the event location

Prototype:

void on_my_toggled(const Glib::ustring& path)

---

Friends And Related Function Documentation

Gtk::CellRendererToggle* wrap	(	GtkCellRendererToggle *	object,
		bool	take_copy = false
	)			[related]

A Glib::wrap() method for this object.

Parameters:

	object	The C instance.
	take_copy	False if the result should take ownership of the C instance. True if it should take a new copy or ref.

Returns:

A C++ instance that wraps this C instance.

---

The documentation for this class was generated from the following file:

• gtkmm/cellrenderertoggle.h
