Gtk::TreeViewColumn Class Reference
[TreeView Classes]

Typedefed as Gtk::TreeView::Column. More...

Collaboration diagram for Gtk::TreeViewColumn:

Public Types
typedef TreeViewColumn	Column
typedef sigc::slot< void, CellRenderer*, const Gtk::TreeModel::iterator& >	SlotCellData
	For instance, void on_cell_data(Gtk::CellRenderer* cell, const Gtk::TreeModel::iterator& iter);.
Public Member Functions
virtual	~TreeViewColumn ()
GtkTreeViewColumn*	gobj ()
	Provides access to the underlying C GtkObject.
const GtkTreeViewColumn*	gobj () const
	Provides access to the underlying C GtkObject.
	TreeViewColumn ()
	TreeViewColumn (const Glib::ustring& title)
	TreeViewColumn (const Glib::ustring& title, CellRenderer& cell)
template<class T_ModelColumnType >
	TreeViewColumn (const Glib::ustring& title, const TreeModelColumn< T_ModelColumnType >& column)
	Create a default view column for the given model column type.
void	pack_start (CellRenderer& cell, bool expand=true)
	Packs the cell into the beginning of the column.
void	pack_end (CellRenderer& cell, bool expand=true)
	Adds the cell to end of the column.
template<class T_ModelColumnType >
void	pack_start (const TreeModelColumn< T_ModelColumnType >& column, bool expand=true)
	Creates an appropriate CellRenderer for the column, and packs that cell into the beginning of the column.
template<class T_ModelColumnType >
void	pack_end (const TreeModelColumn< T_ModelColumnType >& column, bool expand=true)
	Creates an appropriate CellRenderer for the column, and packs that cell at the end of the column.
void	clear ()
	Unsets all the mappings on all renderers on the tree_column.
CellRenderer*	get_first_cell_renderer ()
	Gets the CellRenderer for the column.
const CellRenderer*	get_first_cell_renderer () const
	Gets the CellRenderer for the column.
Glib::ListHandle< CellRenderer* >	get_cell_renderers ()
	Returns a list of all the cell renderers in the column, in no particular order.
Glib::ListHandle< const CellRenderer* >	get_cell_renderers () const
	Returns a list of all the cell renderers in the column, in no particular order.
void	add_attribute (CellRenderer& cell_renderer, const Glib::ustring& attribute, int column)
	Adds an attribute mapping to the list in tree_column.
void	add_attribute (const Glib::PropertyProxy_Base& property, const TreeModelColumnBase& column)
void	add_attribute (Gtk::CellRenderer& cell, const Glib::ustring& property_name, const TreeModelColumnBase& column)
void	set_renderer (Gtk::CellRenderer& renderer, const TreeModelColumnBase& column)
	Associate a view CellRenderer with a model column, so that the CellRenderer renders the data in the model column.
void	set_cell_data_func (CellRenderer& cell_renderer, const SlotCellData& slot)
	Sets the slot callback to use for the column.
void	unset_cell_data_func (CellRenderer& cell_renderer)
	Removes a previously set callback slot.
void	clear_attributes (CellRenderer& cell_renderer)
	Clears all existing attributes previously set with set_attributes().
void	set_spacing (int spacing)
	Sets the spacing field of tree_column, which is the number of pixels to place between cell renderers packed into it.
int	get_spacing () const
	Returns the spacing of tree_column.
void	set_visible (bool visible=true)
	Sets the visibility of tree_column.
bool	get_visible () const
	Returns `true` if tree_column is visible.
void	set_resizable (bool resizable=true)
	If resizable is `true`, then the user can explicitly resize the column by grabbing the outer edge of the column button.
bool	get_resizable () const
	Returns `true` if the tree_column can be resized by the end user.
void	set_sizing (TreeViewColumnSizing type)
	Sets the growth behavior of tree_column to type.
TreeViewColumnSizing	get_sizing ()
	Returns the current type of tree_column.
int	get_width () const
	Returns the current size of tree_column in pixels.
int	get_fixed_width () const
	Gets the fixed width of the column.
void	set_fixed_width (int fixed_width)
	Sets the size of the column in pixels.
void	set_min_width (int min_width)
	Sets the minimum width of the tree_column.
int	get_min_width () const
	Returns the minimum width in pixels of the tree_column, or -1 if no minimum width is set.
void	set_max_width (int max_width)
	Sets the maximum width of the tree_column.
int	get_max_width () const
	Returns the maximum width in pixels of the tree_column, or -1 if no maximum width is set.
void	clicked ()
	Emits the "clicked" signal on the column.
void	set_title (const Glib::ustring& title)
	Sets the title of the tree_column.
Glib::ustring	get_title () const
	Returns the title of the widget.
void	set_expand (bool expand=true)
	Sets the column to take available extra space.
bool	get_expand () const
	Return `true` if the column expands to take any available space.
void	set_clickable (bool clickable=true)
	Sets the header to be active if active is `true`.
bool	get_clickable () const
	Returns `true` if the user can click on the header for the column.
void	set_widget (Gtk::Widget& widget)
	Sets the widget in the header to be widget.
Widget*	get_widget ()
	Returns the Gtk::Widget in the button on the column header.
const Widget*	get_widget () const
	Returns the Gtk::Widget in the button on the column header.
void	set_alignment (float xalign)
	Sets the alignment of the title or custom widget inside the column header.
void	set_alignment (AlignmentEnum xalign)
	Sets the alignment of the title or custom widget inside the column header.
float	get_alignment () const
	Returns the current x alignment of tree_column.
void	set_reorderable (bool reorderable=true)
	If reorderable is `true`, then the column can be reordered by the end user dragging the header.
bool	get_reorderable () const
	Returns `true` if the tree_column can be reordered by the user.
void	set_sort_column (const TreeModelColumnBase& sort_column_id)
	Sets the logical sort_column_id that this column sorts on when this column is selected for sorting.
void	set_sort_column (int sort_column_id)
	Sets the logical sort_column_id that this column sorts on when this column is selected for sorting.
void	set_sort_column_id (const TreeModelColumnBase& sort_column_id)
void	set_sort_column_id (int sort_column_id)
int	get_sort_column_id () const
	Gets the logical sort_column_id that the model sorts on when this column is selected for sorting.
void	set_sort_indicator (bool setting)
	Call this function with a setting of `true` to display an arrow in the header button indicating the column is sorted.
bool	get_sort_indicator () const
	Gets the value set by set_sort_indicator().
void	set_sort_order (SortType order)
	Changes the appearance of the sort indicator.
SortType	get_sort_order () const
	Gets the value set by set_sort_order().
void	cell_set_cell_data (const Glib::RefPtr< TreeModel >& tree_model, const TreeModel::iterator& iter, bool is_expander, bool is_expanded)
	Sets the cell renderer based on the tree_model and iter.
void	cell_get_size (Gdk::Rectangle& cell_area, int& x_offset, int& y_offset, int& width, int& height) const
	Obtains the width and height needed to render the column.
void	cell_get_size (const Gdk::Rectangle& cell_area, int& x_offset, int& y_offset, int& width, int& height) const
	Obtains the width and height needed to render the column.
bool	cell_is_visible () const
	Returns `true` if any of the cells packed into the tree_column are visible.
void	focus_cell (CellRenderer& cell)
	Sets the current keyboard focus to be at cell, if the column contains 2 or more editable and activatable cells.
bool	get_cell_position (const CellRenderer& cell_renderer, int& start_pos, int& width) const
	Obtains the horizontal position and size of a cell in a column.
void	queue_resize ()
	Flags the column, and the cell renderers added to this column, to have their sizes renegotiated.
TreeView*	get_tree_view ()
	Returns the Gtk::TreeView wherein tree_column has been inserted.
const TreeView*	get_tree_view () const
	Returns the Gtk::TreeView wherein tree_column has been inserted.
Glib::SignalProxy0< void >	signal_clicked ()
Glib::PropertyProxy< bool >	property_visible ()
	Whether to display the column.
Glib::PropertyProxy_ReadOnly < bool >	property_visible () const
	Whether to display the column.
Glib::PropertyProxy_ReadOnly< int >	property_width () const
	Current width of the column.
Glib::PropertyProxy < TreeViewColumnSizing >	property_sizing ()
	Resize mode of the column.
Glib::PropertyProxy_ReadOnly < TreeViewColumnSizing >	property_sizing () const
	Resize mode of the column.
Glib::PropertyProxy< int >	property_fixed_width ()
	Current fixed width of the column.
Glib::PropertyProxy_ReadOnly< int >	property_fixed_width () const
	Current fixed width of the column.
Glib::PropertyProxy< int >	property_min_width ()
	Minimum allowed width of the column.
Glib::PropertyProxy_ReadOnly< int >	property_min_width () const
	Minimum allowed width of the column.
Glib::PropertyProxy< int >	property_max_width ()
	Maximum allowed width of the column.
Glib::PropertyProxy_ReadOnly< int >	property_max_width () const
	Maximum allowed width of the column.
Glib::PropertyProxy < Glib::ustring >	property_title ()
	Title to appear in column header.
Glib::PropertyProxy_ReadOnly < Glib::ustring >	property_title () const
	Title to appear in column header.
Glib::PropertyProxy< bool >	property_expand ()
	Column gets share of extra width allocated to the widget.
Glib::PropertyProxy_ReadOnly < bool >	property_expand () const
	Column gets share of extra width allocated to the widget.
Glib::PropertyProxy< bool >	property_clickable ()
	Whether the header can be clicked.
Glib::PropertyProxy_ReadOnly < bool >	property_clickable () const
	Whether the header can be clicked.
Glib::PropertyProxy< Widget* >	property_widget ()
	Widget to put in column header button instead of column title.
Glib::PropertyProxy_ReadOnly < Widget* >	property_widget () const
	Widget to put in column header button instead of column title.
Glib::PropertyProxy< float >	property_alignment ()
	X Alignment of the column header text or widget.
Glib::PropertyProxy_ReadOnly < float >	property_alignment () const
	X Alignment of the column header text or widget.
Glib::PropertyProxy< bool >	property_reorderable ()
	Whether the column can be reordered around the headers.
Glib::PropertyProxy_ReadOnly < bool >	property_reorderable () const
	Whether the column can be reordered around the headers.
Glib::PropertyProxy< bool >	property_sort_indicator ()
	Whether to show a sort indicator.
Glib::PropertyProxy_ReadOnly < bool >	property_sort_indicator () const
	Whether to show a sort indicator.
Glib::PropertyProxy< SortType >	property_sort_order ()
	Sort direction the sort indicator should indicate.
Glib::PropertyProxy_ReadOnly < SortType >	property_sort_order () const
	Sort direction the sort indicator should indicate.
Protected Member Functions
virtual void	on_clicked ()
Related Functions
(Note that these are not member functions.)
Gtk::TreeViewColumn*	wrap (GtkTreeViewColumn* object, bool take_copy=false)
	A Glib::wrap() method for this object.

Detailed Description

Typedefed as Gtk::TreeView::Column.

This is a visible column in a Gtk::TreeView widget. It determines the geometry, type.

Member Typedef Documentation

typedef TreeViewColumn Gtk::TreeViewColumn::Column

typedef sigc::slot<void, CellRenderer*, const Gtk::TreeModel::iterator&> Gtk::TreeViewColumn::SlotCellData

For instance, void on_cell_data(Gtk::CellRenderer* cell, const Gtk::TreeModel::iterator& iter);.

This function is used instead of the standard attributes mapping for setting the column value, and should set the value of the column's cell renderer as appropriate.

Constructor & Destructor Documentation

virtual Gtk::TreeViewColumn::~TreeViewColumn ( ) [virtual]

Gtk::TreeViewColumn::TreeViewColumn ( )

Gtk::TreeViewColumn::TreeViewColumn ( const Glib::ustring & title ) [explicit]

Gtk::TreeViewColumn::TreeViewColumn	(	const Glib::ustring &	title,
		CellRenderer&	cell
	)

template <class T_ModelColumnType >

Gtk::TreeViewColumn::TreeViewColumn	(	const Glib::ustring &	title,
		const TreeModelColumn< T_ModelColumnType >&	column
	)			`[inline]`

Create a default view column for the given model column type.

Member Function Documentation

void Gtk::TreeViewColumn::add_attribute	(	Gtk::CellRenderer&	cell,
		const Glib::ustring &	property_name,
		const TreeModelColumnBase&	column
	)

void Gtk::TreeViewColumn::add_attribute	(	const Glib::PropertyProxy_Base &	property,
		const TreeModelColumnBase&	column
	)

void Gtk::TreeViewColumn::add_attribute	(	CellRenderer&	cell_renderer,
		const Glib::ustring &	attribute,
		int	column
	)

Adds an attribute mapping to the list in tree_column.

The column is the column of the model to get a value from, and the attribute is the parameter on cell_renderer to be set from the value. So for example if column 2 of the model contains strings, you could have the "text" attribute of a Gtk::CellRendererText get its values from column 2.

Parameters:

	cell_renderer	The Gtk::CellRenderer to set attributes on.
	attribute	An attribute on the renderer.
	column	The column position on the model to get the attribute from.

void Gtk::TreeViewColumn::cell_get_size	(	const Gdk::Rectangle&	cell_area,
		int &	x_offset,
		int &	y_offset,
		int &	width,
		int &	height
	)			const

Obtains the width and height needed to render the column.

This is used primarily by the Gtk::TreeView.

Parameters:

	cell_area	The area a cell in the column will be allocated.
	x_offset	Location to return x offset of a cell relative to cell_area.
	y_offset	Location to return y offset of a cell relative to cell_area.
	width	Location to return width needed to render a cell.
	height	Location to return height needed to render a cell.

void Gtk::TreeViewColumn::cell_get_size	(	Gdk::Rectangle&	cell_area,
		int &	x_offset,
		int &	y_offset,
		int &	width,
		int &	height
	)			const

Obtains the width and height needed to render the column.

This is used primarily by the Gtk::TreeView.

Deprecated:: Use the cell_get_size() method override that takes a const cell_area.

Parameters:

	cell_area	The area a cell in the column will be allocated.
	x_offset	Location to return x offset of a cell relative to cell_area.
	y_offset	Location to return y offset of a cell relative to cell_area.
	width	Location to return width needed to render a cell.
	height	Location to return height needed to render a cell.

bool Gtk::TreeViewColumn::cell_is_visible ( ) const

Returns true if any of the cells packed into the tree_column are visible.

For this to be meaningful, you must first initialize the cells with cell_set_cell_data()

Returns:: true, if any of the cells packed into the tree_column are currently visible.

void Gtk::TreeViewColumn::cell_set_cell_data	(	const Glib::RefPtr< TreeModel >&	tree_model,
		const TreeModel::iterator&	iter,
		bool	is_expander,
		bool	is_expanded
	)

Sets the cell renderer based on the tree_model and iter.

That is, for every attribute mapping in tree_column, it will get a value from the set column on the iter, and use that value to set the attribute on the cell renderer. This is used primarily by the Gtk::TreeView.

Parameters:

	tree_model	The Gtk::TreeModel to to get the cell renderers attributes from.
	iter	The Gtk::TreeIter to to get the cell renderer's attributes from.
	is_expander	`true`, if the row has children.
	is_expanded	`true`, if the row has visible children.

void Gtk::TreeViewColumn::clear ( )

Unsets all the mappings on all renderers on the tree_column.

void Gtk::TreeViewColumn::clear_attributes ( CellRenderer& cell_renderer )

Clears all existing attributes previously set with set_attributes().

Parameters:

cell_renderer

A Gtk::CellRenderer to clear the attribute mapping on.

void Gtk::TreeViewColumn::clicked ( )

Emits the "clicked" signal on the column.

This function will only work if tree_column is clickable.

void Gtk::TreeViewColumn::focus_cell ( CellRenderer& cell )

Sets the current keyboard focus to be at cell, if the column contains 2 or more editable and activatable cells.

Since gtkmm 2.2:

Parameters:

cell

A Gtk::CellRenderer.

float Gtk::TreeViewColumn::get_alignment ( ) const

Returns the current x alignment of tree_column.

This value can range between 0.0 and 1.0.

Returns:: The current alignent of tree_column.

bool Gtk::TreeViewColumn::get_cell_position	(	const CellRenderer&	cell_renderer,
		int &	start_pos,
		int &	width
	)			const

Obtains the horizontal position and size of a cell in a column.

If the cell is not found in the column, start_pos and width are not changed and false is returned.

Parameters:

	cell_renderer	A Gtk::CellRenderer.
	start_pos	Return location for the horizontal position of cell within tree_column.
	width	Return location for the width of cell.

Returns:: true if cell belongs to tree_column.

Glib::ListHandle<const CellRenderer*> Gtk::TreeViewColumn::get_cell_renderers ( ) const

Returns a list of all the cell renderers in the column, in no particular order.

Returns:: A list of Gtk::CellRenderers.

Glib::ListHandle<CellRenderer*> Gtk::TreeViewColumn::get_cell_renderers ( )

Returns a list of all the cell renderers in the column, in no particular order.

Returns:: A list of Gtk::CellRenderers.

bool Gtk::TreeViewColumn::get_clickable ( ) const

Returns true if the user can click on the header for the column.

Returns:: true if user can click the column header.

bool Gtk::TreeViewColumn::get_expand ( ) const

Return true if the column expands to take any available space.

Since gtkmm 2.4:

Returns:: true, if the column expands.

const CellRenderer* Gtk::TreeViewColumn::get_first_cell_renderer ( ) const

Gets the CellRenderer for the column.

You should dynamic_cast<> to the expected derived CellRenderer type. This assumes that the TreeViewColumn contains only one CellRenderer.

CellRenderer* Gtk::TreeViewColumn::get_first_cell_renderer ( )

Gets the CellRenderer for the column.

You should dynamic_cast<> to the expected derived CellRenderer type. This assumes that the TreeViewColumn contains only one CellRenderer.

int Gtk::TreeViewColumn::get_fixed_width ( ) const

Gets the fixed width of the column.

This value is only meaning may not be the actual width of the column on the screen, just what is requested.

Returns:: The fixed width of the column.

int Gtk::TreeViewColumn::get_max_width ( ) const

Returns the maximum width in pixels of the tree_column, or -1 if no maximum width is set.

Returns:: The maximum width of the tree_column.

int Gtk::TreeViewColumn::get_min_width ( ) const

Returns the minimum width in pixels of the tree_column, or -1 if no minimum width is set.

Returns:: The minimum width of the tree_column.

bool Gtk::TreeViewColumn::get_reorderable ( ) const

Returns true if the tree_column can be reordered by the user.

Returns:: true if the tree_column can be reordered by the user.

bool Gtk::TreeViewColumn::get_resizable ( ) const

Returns true if the tree_column can be resized by the end user.

Returns:: true, if the tree_column can be resized.

TreeViewColumnSizing Gtk::TreeViewColumn::get_sizing ( )

Returns the current type of tree_column.

Returns:: The type of tree_column.

int Gtk::TreeViewColumn::get_sort_column_id ( ) const

Gets the logical sort_column_id that the model sorts on when this column is selected for sorting.

See set_sort_column_id().

Returns:: The current sort_column_id for this column, or -1 if this column can't be used for sorting.

bool Gtk::TreeViewColumn::get_sort_indicator ( ) const

Gets the value set by set_sort_indicator().

Returns:: Whether the sort indicator arrow is displayed.

SortType Gtk::TreeViewColumn::get_sort_order ( ) const

Gets the value set by set_sort_order().

Returns:: The sort order the sort indicator is indicating.

int Gtk::TreeViewColumn::get_spacing ( ) const

Returns the spacing of tree_column.

Returns:: The spacing of tree_column.

Glib::ustring Gtk::TreeViewColumn::get_title ( ) const

Returns the title of the widget.

Returns:: The title of the column. This string should not be modified or freed.

const TreeView* Gtk::TreeViewColumn::get_tree_view ( ) const

Returns the Gtk::TreeView wherein tree_column has been inserted.

If column is currently not inserted in any tree view, 0 is returned.

Since gtkmm 2.12:

Returns:: The tree view wherein column has been inserted if any, 0 otherwise.

TreeView* Gtk::TreeViewColumn::get_tree_view ( )

Returns the Gtk::TreeView wherein tree_column has been inserted.

If column is currently not inserted in any tree view, 0 is returned.

Since gtkmm 2.12:

Returns:: The tree view wherein column has been inserted if any, 0 otherwise.

bool Gtk::TreeViewColumn::get_visible ( ) const

Returns true if tree_column is visible.

Returns:: Whether the column is visible or not. If it is visible, then the tree will show the column.

const Widget* Gtk::TreeViewColumn::get_widget ( ) const

Returns the Gtk::Widget in the button on the column header.

If a custom widget has not been set then 0 is returned.

Returns:: The Gtk::Widget in the column header, or 0.

Widget* Gtk::TreeViewColumn::get_widget ( )

Returns the Gtk::Widget in the button on the column header.

If a custom widget has not been set then 0 is returned.

Returns:: The Gtk::Widget in the column header, or 0.

int Gtk::TreeViewColumn::get_width ( ) const

Returns the current size of tree_column in pixels.

Returns:: The current width of tree_column.

const GtkTreeViewColumn* Gtk::TreeViewColumn::gobj ( ) const [inline]

Provides access to the underlying C GtkObject.

Reimplemented from Gtk::Object.

GtkTreeViewColumn* Gtk::TreeViewColumn::gobj ( ) [inline]

Provides access to the underlying C GtkObject.

Reimplemented from Gtk::Object.

virtual void Gtk::TreeViewColumn::on_clicked ( ) [protected, virtual]

template <class T_ModelColumnType >

void Gtk::TreeViewColumn::pack_end	(	const TreeModelColumn< T_ModelColumnType >&	column,
		bool	expand = `true`
	)			`[inline]`

Creates an appropriate CellRenderer for the column, and packs that cell at the end of the column.

If expand is false, then the cell is allocated no more space than it needs. Any unused space is divided evenly between cells for which expand is true.

You can use get_first_cell_renderer() or get_cell_renderers() to access the generated CellRenderer.

Parameters:

	column	The model column that will be rendered by the view cell.
	expand	`true` if the cell is to be given extra space allocated to the view column.

void Gtk::TreeViewColumn::pack_end	(	CellRenderer&	cell,
		bool	expand = `true`
	)

Adds the cell to end of the column.

If expand is false, then the cell is allocated no more space than it needs. Any unused space is divided evenly between cells for which expand is true.

Parameters:

	cell	The Gtk::CellRenderer.
	expand	`true` if cell is to be given extra space allocated to tree_column.

template <class T_ModelColumnType >

void Gtk::TreeViewColumn::pack_start	(	const TreeModelColumn< T_ModelColumnType >&	column,
		bool	expand = `true`
	)			`[inline]`

Creates an appropriate CellRenderer for the column, and packs that cell into the beginning of the column.

If expand is false, then the cell is allocated no more space than it needs. Any unused space is divided evenly between cells for which expand is true.

You can use get_first_cell_renderer() or get_cell_renderers() to access the generated CellRenderer.

Parameters:

	column	The model column that will be rendered by the view cell.
	expand	`true` if the cell is to be given extra space allocated to the view column.

void Gtk::TreeViewColumn::pack_start	(	CellRenderer&	cell,
		bool	expand = `true`
	)

Packs the cell into the beginning of the column.

If expand is false, then the cell is allocated no more space than it needs. Any unused space is divided evenly between cells for which expand is true.

Parameters:

	cell	The Gtk::CellRenderer.
	expand	`true` if cell is to be given extra space allocated to tree_column.

Glib::PropertyProxy_ReadOnly<float> Gtk::TreeViewColumn::property_alignment ( ) const

X Alignment of the column header text or widget.
